AM – S 300 A

Multi-purpose AM - S 300 A arc spray device is suitable for coating processes aimed at protecting large and extensive surfaces from corrosion. Various metal-steel wires, cored wires, zinc, or aluminum wires suitable for every need can be attached within a few minutes and sprayed onto the desired surface.

Machine Specifications

An ideal coating device used for galvanizing materials that cannot be coated with hot-dip galvanizing method. It provides fast and economical solutions for coating very large-sized materials or materials under pressure. Due to its rough coating surface, it is suitable for paint applications. Coating thickness can range from 50 microns to 1000 microns. Coated surfaces provide protection for nearly 40 years depending on the material's conditions.

Technical Specifications

• Voltage: 380-400V 50Hz, 3 Phase
• Maximum Output (Continuous): 10.8 kVA (100% ED)
• Coating Wire Diameters: 1.60 mm / 2.00 mm / 2.50 mm
• Manual Spray Gun: AM-S (Air Motor)
• Spray Cable and Hose Set: 7 meters (Maximum 20 meters if requested)
• Wire Feed Mechanism from Coil (Feeding from Barrel if requested)
• Coating Capacity:
     • Zinc Coating: 30kg/h
     • Aluminum Coating: 9kg/h
     • Steel Coating: 12 kg/h
• Protective Mask is recommended for the Operator.

Applications

• Shipbuilding / Maritime sector
• Bridges (Concrete and Steel)
• Structural steel materials
• Oil and gas production facilities
• Energy Sector
• Wind turbine towers
• Fences / Gates
• Coating of engineering components
• Boiler corrosion coatings, and more...
